What is the difference between Mil vs Gauge in reqard to vinyl pool liners?
Do you want to know what the difference between Mil and Gauge in vinyl liners? We think it was created by some marketing people to confuse us. So we did the asking of the questions with all of our liner producers and got the answers.
Mil (MIL) is an actual physical size measurement. One Mil = 1/1000th or 0.001 of an inch. A liner that is described as 20-Mil thick is actually 0.020 of an inch thick. And this is consistent amoung all the manufacturers.
Gauge (Ga) is a made up marketing term and its' meaning can be vary with each liner manufacturers. It is loosly based on the weight/ Square Yard combined with actual thickness of the line, which is incorrectly and incoherently to be used for thickness comparisons. Swimlline (arguably the largest liner manufacturer) used to sell their above gound liners using Mil where 15-Mil was their standard liner thickness and 20-Mil was their Heavy Duty liner. Then they changed to Gauge where 20ga was their standard liner and 25ga was the heavy duty, but the actual thickness of the liner didn't change. Over the years even the actual thickness became thinner and now they have dropped the 'Gauge' terminology altogether and just have 'Standard' or 'Heavy Duty' labeled liners. Why? A thinner liner is usually cheaper to make. A larger 'Gauge' number will confuse many pool owners into thinking that a 25ga liner is thicker than a 20-Mil liner. So a perceived thicker liner at a lower price will sell more liners and it works.
Liner Thickness in Gauge vs Actual Thickness in Mil | |
|---|---|
| Gauge (ga) | Estimated Actual Thickness in Mil |
| 20ga | ~11-13 MIL |
| 25ga | ~14-15 MIL |
| 30ga | ~16-17 MIL |
| 35ga | ~18-19 MIL |
| 40ga | ~20-22 MIL |
Pro-Tip - always shop and compare using MIL and look at how the manufacturer warrants the liner. Totally ignore the number used if liner is described using 'Gauge'. Ask for the actual MIL thickness, or use the chart above for actual thickness (durability) comparison, if they cannot or will not provide the MIL thickness.
